Elecbee ADF4351 Wideband RF Signal Generator 35MHz-4.4GHz Sweep Synthesizer SMA PC Control

ADF4351 Wideband RF Signal Generator and Sweep Synthesizer

Elecbee ADF4351 Wideband RF Signal Generator is a programmable RF sweep synthesizer designed for SDR development, RF laboratory testing, microwave communication experiments, wireless engineering, signal source generation, and embedded RF applications. The module supports fixed-frequency and sweep-frequency operation with touchscreen control and PC software frequency management.

Technical Specifications

• Main RF Chipset: ADF4351 Wideband PLL Frequency Synthesizer
• RF Frequency Range: 35MHz-4.4GHz
• RF Output Modes:
  • 2.2GHz-4.4GHz Fundamental Sine Wave Output
  • 35MHz-2.2GHz Divider Square Wave Output
• Frequency Functions: Fixed Frequency / Sweep Frequency
• Sweep Control: Full Touchscreen Frequency Adjustment
• PC Software Control: Supported
• Amplitude Adjustment: 4-Level RF Output Control
• External Reference Clock Input: Supported
• RF Output Connector: SMA Female
• Power Interface: USB Type-C
• Power Supply: 5V DC @ 0.2A
• Board Dimensions: 80 × 60 × 10mm
• Weight: 110g

RF Engineering and SDR Applications

The ADF4351 RF synthesizer module is suitable for SDR systems, RF frequency testing, microwave signal generation, local oscillator applications, antenna analysis, spectrum experiments, wireless communication development, RF laboratory workflows, and embedded RF engineering integration.

Stable Wideband RF Architecture

The module adopts RF PCB routing and circuit architecture based on the official Analog Devices evaluation board reference design to improve signal integrity, phase noise performance, RF stability, and frequency synthesis reliability. Adjustable RF amplitude output supports multiple communication and laboratory testing environments.

System Compatibility and Integration

The RF signal generator supports programmable PC frequency management, touchscreen sweep control, SMA RF connection, and external reference clock synchronization. It is compatible with SDR development platforms, RF laboratories, microwave communication systems, wireless testing environments, and embedded RF engineering projects.
