Elecbee RF Coaxial connector Standard SMA Jack Right Angle Solder Type for PCB mount
SKU: EB-007-0315
Favorites
Key Features
- Durable SMA right-angle connector for reliable RF connections.
- Solder-type PCB mount ensures high-strength, stable connection.
- Ideal for compact designs requiring space-saving components.
Show More
Specifications
Attribute
Value
Search
Connector Type
Jack
Number of Ports
1
Mounting Type
Panel Mount
Mounting Feature
Edge Mount
Termination
Solder
Contact Type
Female Pin
Shell Finish
Gold Plated
Impendance
50 Ohms
Frequency Max
6 GHz
Connector Series
SMA
Color
Gold
Fastening Type
Threaded
Orientation
Right Angled
Shell Material
Copper Alloy
Description
Description
This is a SMA straight connector PCB Edge type with impedance of 50 ohms; highly suitable for prototyping with the cellular devices and GPS that needs an antenna connection. The female signal pin present in this connector correctly mate with the original SMA type antenna and ensures reliable functioning.
