DSTIKE Deauther OLED V8 ESP8266 2.4GHz Wi-Fi Development Board Kit with 1.3-Inch SH1106 OLED, DS3231 RTC, Case and Antenna

The DSTIKE Deauther OLED V8 is an ESP8266-based development board designed for authorized 2.4GHz Wi-Fi network testing, wireless-security education and custom ESP8266 software projects. Compared with the previous V7 version, the V8 revision upgrades the battery-protection chip and modifies the power circuitry to improve operating stability.

2.4GHz Wi-Fi Testing and Development: The board comes with ESP8266 Deauther software installed and provides Wi-Fi scanning, packet monitoring, beacon testing, probe testing and deauthentication testing functions for networks and devices you own or are authorized to test. It supports 2.4GHz IEEE 802.11 b/g/n Wi-Fi only and does not support 5GHz Wi-Fi or Bluetooth. The board can also be programmed for custom ESP8266 development projects.

OLED Display and Onboard Controls: The integrated 1.3-inch SH1106 OLED displays operating menus, packet-monitor information and an adjustable clock. A three-way momentary slide switch provides convenient menu navigation and function selection without requiring separate control hardware. The onboard DS3231 real-time clock operates when a compatible battery is connected.

Upgraded V8 Power System: The integrated charging system supports one 18650 lithium-ion cell with a charging current of up to 1A. Four LEDs indicate battery status in real time, while the upgraded V8 protection circuit provides short-circuit, overcharge, over-discharge, over-temperature and reverse-polarity protection. An indicator light warns when the battery is installed with the incorrect orientation.

Power Consumption and Operating Time: According to the supplier's stated test conditions, typical power consumption is approximately 80–100mA, and operating time can reach up to 35 hours when a 3500mAh 18650 cell is used. Actual operating time may vary according to battery capacity, condition and usage.

GPIO Expansion: Seven GPIO breakout connections are available for development and prototyping, including GPIO16, GPIO3 RXD, GPIO1 TXD, GPIO5 SDA, GPIO4 SCL, GPIO0 and GPIO2. The board also provides GND, 3.3V and 5V connections for compatible external circuits. The onboard WS2812B LED is connected to GPIO15, and the high-brightness LED is controlled through GPIO16.

Package Contents:

• 1 × DSTIKE Deauther OLED V8 development board
• 1 × Enclosure with transparent cover
• 1 × External antenna with right-angle adapter
• Installation screws, nuts and related mounting hardware

Tighten the antenna connector on the enclosure before installing the antenna and observe the polarity markings when inserting the 18650 cell. The 18650 battery is required for portable operation but is not included with this kit.

This product is intended for development, education and authorized security testing. Use its wireless testing functions only on networks and devices that you own or have explicit permission to test, and comply with all applicable laws and regulations in your country or region.
