Elecbee 2-Channel 12V Relay Module with Optocoupler Isolation, 10A 250V AC / 30V DC, Low Level Trigger Expansion Board for Arduino/MCU, Black
SKU: EB-900-0002
Favorites
Key Features
Enhanced Circuit Safety: Integrated optocoupler isolation protects your microcontroller from high-voltage inductive kickback and interference.
High-Capacity Switching: Supports heavy loads up to 10A at 250V AC or 10A at 30V DC, suitable for household appliances and industrial motors.
Visual Status Monitoring: Onboard LED indicators provide real-time feedback, glowing when the relay is energized (closed) and off when released.
Flexible Power Logic: Features a dual-power design (VCC/JD-VCC) with jumper caps for independent system and relay power management.
Easy Mounting: Compact 50.6mm x 38.8mm PCB includes four 3.1mm pre-drilled holes for secure installation in projects or enclosures.
Show More
In-Stock
Qty.
1
Unit Price
€ 2.43€ 2.86
Ext. Price
€ 2.43€ 2.86
€ 2.43€ 2.86
Description
The Elecbee 2-Channel Relay Module is an essential interface expansion board for MCU development, allowing low-power microcontrollers to safely control high-voltage devices. Equipped with optocoupler protection, it provides superior anti-interference capabilities, ensuring that your logic circuits remain isolated from the power load.
- Configuration: SPDT (1 Common, 1 NO, 1 NC)
- Trigger Mode: Low Level Trigger (Sinks Current)
- Mounting Holes: 3.1mm Diameter
Each relay on this board is capable of switching 10A 250V AC or 10A 30V DC. The module features a black PCB with clear labeling for VCC, GND, and IN1-IN2 control ports. Designed for 12V operation, it is a "plug-and-play" solution for Arduino, Raspberry Pi, and PLC automated systems requiring high-current switching.
