Elecbee M12 Panel Receptacles A Code Right Angle 8pin Male Non-shield connector

SKU: EB-400-2287
Favorites

Key Features

Features:

  • M12 Panel Receptacles,A Coded,90°,8 Pin,Male,Front mount,PCB mount,Waterproof
  • thread locking mechanism, anti vibration locking design,12mm thread joint;
  • Easy quick connect and disconnect coupling;xa0
  • High Quality with 30 days 100% Money back;xa0
  • From the OEM Original Factory, same quality with much better price.xa0
Show More
Attribute
Value
Connector Type
Receptacle
Mounting Type
Panel Mount
Contact Type
Male Pin
Shell Finish
Nickel Plated
Number of Positions
8 Pin
Operating Temperature
-20℃~+85℃
Shielding
Unshielded
Ingress Protection
IP67(mated)
Rated Current
2A
Rated Voltage
30V
Connector Series
M12
Color
Silver
Fastening Type
Threaded
Orientation
Right Angled
Shell Material
Copper Alloy
Contact Material
Copper Alloy
Contact Finish
Gold Plated
Insulating Materials
PA66 + GF
Insulation Color
Black
Key
A Code
Wire Gauge
24AWG
Description
