Elecbee M12 Field Wireable Connector B Code Straight 5pin Female Non-shield connector

SKU: EB-400-2129
Favorites
Key Features

Features:

  • M12,FieldWireable Connector,B Code,5Pin,Female, Straight,For Cable,Screw-Joint,No Shield
  • thread locking mechanism, anti vibration locking design，12mm thread joint;
  • Easy quick connect and disconnect coupling;
  • High Quality with 30 days 100% Money back;
  • From the OEM Original Factory, same quality withmuch better price.
Show More
Specifications
Show Similar Products >
Attribute
Value
Search
Connector Type
Plug
Mounting Type
Cable Type
Termination
Screw Terminal
Contact Type
Female Pin
Number of Positions
5 Pin
Operating Temperature
-20℃~+85℃
Shielding
Unshielded
Ingress Protection
IP67(mated）
Rated Current
4A
Rated Voltage
60V
Connector Series
M12
Color
Black
Fastening Type
Threaded
Orientation
Straight
Shell Material
PA66
Contact Material
Copper Alloy
Contact Finish
Gold Plated
Insulating Materials
PA66 + GF
Insulation Color
Black
Key
B Code
Wire Gauge
22AWG
Show Similar Products >
Description

M12 Field Wireable Connector

IP67/68 Weatherproof
|
Plug & Play Connections
|
Rugged Metal Housing

M12 Field Wireable Connector

The M12 field wireable connectors are used to build custom patch cables, provide a quick-disconnect for a device, terminate field devices on an I/O block, or bring multiple sensor signals into one port. M12 field-installable connectors support higher bandwidth while providing an IP67 rated solution for demanding applications.



DIRECT DEAL

EASY ASSEMBLY

QUALITY ASSURANCE

MULTI CORE OPTIONAL

M12 Field Wireable Connetor
Coding A / B / D / T / X
Number of Positions 3 / 4 / 5 / 8 / 12 / 17
Gender Male / Female
Orientation Straight / Right Angle
Mounting Type Cable
Shell Material Metal / Plastic
Termination Style Screw-joint / Solder Type
Shield Shield / Unshielded

M12 Field Wireable TYPE

PRODUCT DESCRIPTION

1. Exquisite Craftsmanship Makes Connections More Secure
  • Thickened pins/long life
  • Copper-zinc material,high resistance,wear resistance
  • Thickened cable,easy to remove and plug,tightly combined and not easy to fall off
3. STABLE PERFORMANCE,STRONG AND DURABLE
  • Hight quality PA66 housing
  • Thread locking mechanism,shock-proof locking design
  • Thickened nylon is anti-corrosion,non-flammable,and has good insulation property

2. Safe and Reliable Meet the Standards to Create Safety
  • Pure copper gold-plated contacts with exc-ellent electrical conductivity
  • Fixed keys and multikeys to prevent blind insertion, misin- sertion, and skewed insertion
  • Strong waterproof performance, in line with IP67/IP68 wa terproof requests
APPLICATION
Miniature sensors
Industrial camera
Electrical car
Packaging, Labeling & Logistic
Factory automation and fieldbus module
