Elecbee GX20 Aviation connector Straight 3 Pin Flange Plug, Receptacle (one Pair) Silver Plated
SKU: EB-405-0041
Favorites
Key Features
High-Strength Connection：
The GX12 Connector features a metal housing for a robust electrical connection and mechanical strength.
Various Pin Configurations：
Available in multiple pin configurations to meet the needs of various devices and applications.
Easy Installation：
Simple design supports quick connection and disconnection, enhancing installation efficiency.
Wide Application：
Widely used in automation, robotics, aerospace, and various other fields.
Show More
Specifications
Attribute
Value
Search
Connector Type
Plug, Receptacle
Mounting Type
Panel Mount
Mounting Feature
Flange
Termination
Solder Cup
Contact Type
Male，Female Pin
Shell Finish
Nickel Plated
Number of Positions
3 Pin
Ingress Protection
IP54
Rated Current
7A
Rated Voltage
250VAC
Connector Series
GX20
Color
Silver
Fastening Type
Threaded
Orientation
Straight
Shell Material
Zinc Alloy
Contact Material
Copper Alloy
Contact Finish
Silver Plated
Insulating Materials
Bakelite
Description
