Elecbee TGC700 0/4-20mA 0-5/10V Voltage Current Signal Generator 20mA Signal Transmitter With LCD 1602 Display

SKU: EB0050411

Favorites

Key Features

Current and voltage signal generator TGC1700 series, can produce dual 0-20mA current signal and 0-10V voltage signal.

The module is easy to use, input data through key operation, and immediately update the output signal.

-1602 display with backlight, standard LCD 1602 interface.

-Active current 0-20mA output, display resolution 0.001mA, control accuracy 0.1mA

Voltage 0-10V output, display resolution 0.001V, load current less than 10mA

Input voltage polarity protection

Simulate the output of the transmitter

Applications:

Signal generator

Value regulator

Instrument calibration

Power Interface:

CN1 "+" indicates positive input power

CN1 "-" indicates the negative input power (GND)

Output signal:

CN2 "OI" indicates active current output

CN2 "G" indicates active current output common (GND)

CN3 "OV" indicates voltage output

CN3 "G" indicates the voltage output common (GND)

Use method and procedure:

FN: Function switching

Press FN (K4)"-" the cursor moves up and down in the first and second lines. Switch current and voltage output gears.

SET: Shift operation

Press SET (K3): The "-" cursor moves to the left and adjusts the increment and decrease steps. "-" indicates the current output bit to be set.

UP: (K1) Incremental increase

DN: (K2) Incremental reduction

Power supply and connection annunciator, push the code switch S1 to turn on the power, the display screen lights up, display as shown:

Specifications

Show Similar Products >

Attribute

Value

Model

TGC700

Show Similar Products >

Description

Package includes:

1 x Signal Generator
