Elecbee ESP32-DevKitC core Board ESP32 Development Board ESP32-WROOM-32D WiFi Bluetooth Development Board for Arduino IDE

Developing low-power IoT applications often requires balancing complex wireless protocols with limited hardware accessibility. This Elecbee ESP32-DevKitC Development Board solves the hurdle of rapid prototyping by integrating the ESP32-WROOM-32D module onto a user-friendly platform. Whether you are building smart home devices or industrial monitoring systems, this board provides a reliable, plug-and-play foundation that eliminates the need for manual module soldering.

This evaluation board is engineered for professional developers and hardware engineers. The technical architecture includes:

• Core Module: ESP32-WROOM-32D (Dual-core 32-bit MCU)
• USB Interface: Modern Type-C connector for power and debugging
• Wireless Specs: 802.11 b/g/n WiFi and Dual-mode Bluetooth
• I/O Accessibility: Full GPIO breakout for PWM, ADC, DAC, and I2C/SPI peripherals

Technical product information: The Elecbee ESP32-DevKitC operates at a standard 3.3V logic level, with the Type-C interface supporting high-current power input for peripheral-heavy projects. The onboard LDO regulator ensures stable voltage supply to the ESP32 chip, preventing resets during high-power WiFi transmission bursts. Designed for compatibility with Arduino IDE, Espressif IDF, and MicroPython, this board is the industry-standard choice for scalable Internet of Things deployments.
