Elecbee HMC241 DC3.5 GHz Wireless Radio Frequency Single Pole Four Throw Switch Band Switching Radio Frequency Switch

SKU: EB0048528

Favorites

Key Features

Supply voltage: 5V

Low insertion loss (@2 GHz): 0.7 dB

Single positive power supply: Vdd = +5V

Integrated 2:4 TTL decoder

16-pin QSOP package

Products comply with RoHS standards

PCB size: 50*50*13MM without SMA socket

Product weight: 15 g

Application:

1. Base stations and portable wireless systems

2. CATV / DBS

3. Wireless local loop

4. Test equipment

Control level: B, A = L, L (ie RFC is connected to RF1)

The S21 curve from RFC to RF1 is as follows: (conduction characteristic)

Specifications

Show Similar Products >

Attribute

Value

Wireless Capability

Wi-Fi

Wi‑Fi Standard

802.11B/G/N

Model

HMC241

Show Similar Products >

Description

1 x Radio Frequency Switch

Description:

HMC241 is a general-purpose low-cost non-reflective SP4T switch in a 16-pin QSOP package. The switching frequency range of the device is DC-3.5 GHz, with high isolation and 0.7 dB low insertion loss at 2 GHz. The switch provides single positive bias and true TTL/CMOS compatibility. The switch integrates a 2:4 decoder, and only two control lines and a positive bias are needed to select each path, which can replace the 8 control lines normally required for GaAs SP4T switches.

Package includes:

1 x Radio Frequency Switch
