Elecbee Push Pull Self-Locking Connector B Series 3B TPG Elbow (90°) plug - With cable clamp Male 5Pin
SKU: EB-TPG.3B.305.CLAD
Favorites
Key Features
- High-frequency performance up to 18GHz with low reflection.
- Durable 50 Ohm SMA connector with nickel plating.
- Compact design with secure thread coupling for minimal loss.
- Ideal for aerospace, telecom, and industrial applications.
- OEM quality at competitive pricing with 30-day money-back.
Show More
Specifications
Attribute
Value
Search
Connector Type
Plug
Mounting Type
Cable Type
Termination
Solder
Contact Type
Male Pin
Shell Finish
Nickel Plated
Number of Positions
5 Pin
Operating Temperature
-55℃~+250℃
Shielding
Shielded
Ingress Protection
IP50
Rated Current
3.5A
Features
Waterproof
Connector Series
B
Color
Silver
Fastening Type
Push-on
Orientation
Right Angled
Shell Material
Copper Alloy
Contact Material
Brass
Contact Finish
Gold Plated
Insulating Materials
PPS
Insulation Color
White
