商品图

Elecbee SP29系列 防水航空连接器 10 pin 焊接弯式对接弯公插头+后螺母插座一对

SKU: EB-410-3015
收藏
主要特点

特征:

  • SP29 系列连接器,弯式,标准型,后螺母安装插座和直角插头,焊接触点,10 针
  • 每款产品均具有 IP68 防护等级,在恶劣环境下表现出色
  • 轻松快速连接和断开联轴器
  • 性价比高、品质好
展开
属性
连接器类型
插头,插座
安装类型
面板安装
端接
焊接
接触件类型
公针,母针
针位数
10芯
阻燃等级
UL94 V-0
工作温度
-40℃~+85℃
侵入防护
IP68
额定电流
25A
额定电压
500VAC
特征
防水
连接器系列
SP29
颜色
黑色, 蓝色
紧固类型
螺纹式
方向
90° 弯式
外壳材料
PA66, PC
接触件材料
黄铜
接触件表面处理
镀金
绝缘材料
PPS
适配线径
11AWG
外壳尺寸
29
绝缘颜色
黑色
描述

配送指南
运费与发货
发货周期
现货商品预计3天内发货。
Elecbee每天下午5点发货一次,周日除外。
发货后,预计送达时间取决于您选择的承运商。
DHL快递:3-7个工作日
DHL电商:12-22个工作日
FedEx国际优先快递:3-7个工作日
EMS:10-15个工作日
挂号航空邮件:15-30个工作日
运费标准您订单的运费可在购物车中查看。
发货选项我们提供DHL、FedEx、EMS、顺丰速运和挂号航空邮件国际配送服务。
发货追踪订单发货后,我们将通过邮件通知您追踪号码。您可以使用“我的订单追踪”功能追踪您的订单。
退货与保修退货通常在发货日期30天内完成退货申请。请联系客服获得退货授权。商品须未使用且保持原包装。运费由客户承担。
保修所有Elecbee购买商品均享有30天无理由退款政策,以及1年制造缺陷保修。
此保修不适用于因客户组装不当、未按说明操作、产品改装、疏忽或不当操作而造成的缺陷。
下单与订购如何订购Elecbee接受在线订单。
加入购物车 > 结账 > 提交订单 > 完成支付 > 发货
支付支持 PayPal、信用卡(包括 Visa、MasterCard、美国运通卡)以及银行转账。
评论
ELECBEE
所有评论均来自已验证的购买者
1 星
0%
2 星
0%
3 星
17%
4 星
17%
5 星
67%
D****s
It is strong, the material is very good, and it is very convenient to use and easy to install. Thank you Elecbee.
F****O
Perfect for my marine project! The gold-plated pins and waterproof design ensure reliable connections even in wet conditions. Soldering was smooth thanks to the quality barrel.
D****a
Solid build and great for high-current applications up to 100A. Took a little time to solder, but the right-angle plug saves space in tight enclosures.
M****q
Used this aviation connector in a drone power system. Threaded coupling keeps it locked in place, and the 10-pin configuration handled all signals cleanly.
A****i
Good connector, but soldering requires precision. Not ideal for beginners. Works well once assembled, though—no signal loss detected.
A****h
Exactly what I needed for outdoor lighting. Waterproof and durable. The rear-nut mount made installation stable on the panel.
有现货:99994
数量
1
单价
$ 8.79
总价
$ 8.79
$ 8.79
1-3个工作日内可发货
数量
P. Unit.
总价
20+
$8.79
$ 175.80
50+
$7.91
$ 395.50
100+
$7.03
$ 703.00
