商品图

Elecbee SA20 2 芯直式公插头 线缆安装 螺丝压接 黑色

SKU: EB-SA2010-P2B-2
收藏
主要特点
展开
Number of Positions
属性
连接器类型
插头
安装类型
线缆安装
端接
螺钉连接
接触件类型
公针
外壳表面处理
阳极氧化
针位数
2芯
工作温度
-40℃~+85℃
侵入防护
IP67
额定电流
10A
额定电压
500VAC
连接器系列
SA20
颜色
黑色
紧固类型
推入式
方向
直式
外壳材料
铝合金
接触件材料
黄铜
接触件表面处理
镀金
绝缘材料
PPS
适配线径
20AWG~10AWG
外壳尺寸
20
绝缘颜色
黑色
键位
A扣
配送指南
运费与发货
发货周期
现货商品预计3天内发货。
Elecbee每天下午5点发货一次,周日除外。
发货后,预计送达时间取决于您选择的承运商。
DHL快递:3-7个工作日
DHL电商:12-22个工作日
FedEx国际优先快递:3-7个工作日
EMS:10-15个工作日
挂号航空邮件:15-30个工作日
运费标准您订单的运费可在购物车中查看。
发货选项我们提供DHL、FedEx、EMS、顺丰速运和挂号航空邮件国际配送服务。
发货追踪订单发货后,我们将通过邮件通知您追踪号码。您可以使用“我的订单追踪”功能追踪您的订单。
退货与保修退货通常在发货日期30天内完成退货申请。请联系客服获得退货授权。商品须未使用且保持原包装。运费由客户承担。
保修所有Elecbee购买商品均享有30天无理由退款政策,以及1年制造缺陷保修。
此保修不适用于因客户组装不当、未按说明操作、产品改装、疏忽或不当操作而造成的缺陷。
下单与订购如何订购Elecbee接受在线订单。
加入购物车 > 结账 > 提交订单 > 完成支付 > 发货
支付支持 PayPal、信用卡(包括 Visa、MasterCard、美国运通卡)以及银行转账。
评论
ELECBEE
所有评论均来自已验证的购买者
1 星
0%
2 星
0%
3 星
20%
4 星
20%
5 星
60%
A****o
Perfect for my outdoor lighting project! The metal housing feels extremely durable and the screw-on design makes it waterproof as advertised. Easy to install with clear pin layout.
S****s
Solid build quality and good connectivity. I used the 4-pin version and it fits snugly. Only wish the instructions were a bit clearer, but overall a reliable connector.
A****r
Exactly what I needed for my marine setup. The high-strength metal body resists corrosion and vibration. Waterproof seal held up in heavy rain. Highly recommend!
d****r
Works well enough, but took some time to figure out the wiring. Good value for multiple pin options, though packaging could be better.
M****h
Great connector for rugged applications. Metal housing gives confidence in durability. Installed in under 10 minutes—true plug-and-play with secure fit.
有现货:99997
数量
1
单价
$ 17.97
总价
$ 17.97
$ 17.97
1-3个工作日内可发货
数量
P. Unit.
总价
10+
$17.07
$ 170.70
20+
$16.17
$ 323.40
100+
$14.38
$ 1438.00
