Elecbee 4G LTE Pole Mount Directional Panel Antenna (50 Ohm) | weBoost 314453

Pole Mount Directional Panel Antenna (50 Ohm) | weBoost 314453 by Wilson Electronics / WilsonPro.

weBoost 4G LTE pole mount directional Panel antenna (314453) kit is designed for mounting outside house or building because it includes pole mounting hardware. This antenna has compact design, offers high performance, and an all-weather operation. It is vertically polarized. It operates on 50 Ohm impedance. It has N-Female Connector at end of attached 9 inch of low-loss coaxial cable. It works on all available cellular signal bands.

Included mounting bracket is adjustable and will accommodate pipe diameters from 1.25 inches to 2 inches (pipe for mounting antenna sold separately - 901117). Mount antenna so that there is at least 3 feet of clearance in front and sides. Position the antenna so that it has the most unobstructed line of sight to the cellular service provider's strongest signal. If you're using a wireless signal booster, make sure that antenna is not pointing across your own roof.

Lightning protection is recommended for all installations, sold separately (50 Ohm Lightning Surge Protector). Take extreme care to ensure that neither you, nor the antenna comes near any electric power lines.

Adjusting antenna for maximum performance:

To adjust antenna for best performance, connect it to your cell phone with an External Adapter and a length of cable (External Antenna Adapters and cables are sold separately). Put the cell phone in test mode and turn the antenna in 10-degree increments while checking the cell phone's signal level. At each point you may need to wait a few seconds as your cell phone updates.

Signal readings usually appear as a negative number (for example, -86). The larger the number, the more powerful the signal (-69 is stronger than -99). Once you have obtained the strongest signal, fully tighten the mounting hardware. After the cell phone signal boster and the rest of the system is performing correctly, weatherproof all connections.

Important: If you're using a wireless signal booster, be sure the antenna is not pointing across the building in which you are trying to get coverage. The antenna should point away from the building to help prevent oscillation (feedback).

Ultra low loss cable is recommended for lengths 20 feet or greater to prevent significant signal loss. We offer Wilson400 2-1000 ft. cables and also offer a wide range of phone adapters to connect your cell phone to a Signal Booster or directly to antenna. To find adapter for your phone, call us.

Technical Specifications.

Check specs. to confirm this 50 Ohm Panel antenna's comparable, or better than any brand in the market including SureCall, RSRF, HiBoost, Cel-Fi, etc.
