Elecbee SP21 Series Waterproof Aviation connector 5 pin Straight Solder Type Male Plug and Female 4-hole flange Socket one pair

SKU: EB-410-2120
Favorites
Key Features
  • 5-pin waterproof aviation connector pair for reliable connections.
  • Rated for 5-100A, ideal for high and low power applications.
  • Gold-plated pins ensure superior conductivity and durability.
  • Threaded coupling for secure, stable connection in harsh environments.
  • Flexible termination options: solder and screw crimping available.
Show More
Attribute
Value
Connector Type
Plug, Receptacle
Mounting Type
Panel Mount
Termination
Solder
Contact Type
Male,Female Pin
Number of Positions
5 Pin
Material Flammability Rating
UL94 V-0
Operating Temperature
-40℃~+85℃
Ingress Protection
IP68
Rated Current
30A
Rated Voltage
500VAC
Features
Waterproof
Connector Series
SP21
Color
Black, Blue
Fastening Type
Threaded
Orientation
Straight
Shell Material
PA66, PC
Contact Material
Brass
Contact Finish
Gold Plated
Insulating Materials
PPS
Cable Diameter
12AWG
Shell Size
21
Insulation Color
Black
